CarboThix ®

TWO COMPONENT. GROUTING RESIN.

Two component grouting resin for cable bolt anchoring and self drilling bolts. An instantly thickening, fast curing, two component silicate resin for high strength bonding of solid bolts and cable anchors. The final mixture thickens very quickly to form a tough, interpenetrating non porous elastic silicate. This minimises leakage from the bolt hole, displacing drilling water helping ensure full encapsulation.

Carbothix Fast has been designed especially for use with our range of UniPass dynamic and static rock bolts. Tested in Australian conditions, Carbothix Fast allows for improved rock bolting productivity.

Advantages

  1. 1 IMMEDIATE LOADING CAPACITY
  2. 2 FULL ENCAPSULATION OF THE ANCHOR
  3. 3 LONG DISTANCE PUMPING

Features

  • Pumpable resin enables load to be taken up in minutes

  • Full encapsulation of anchors

  • Immediate thickening minimising leakage from bolt hole

  • Consistent grout quality ensuring reliable anchoring performance

  • Resistance of grout to water

  • Longer shelf life than resin capsules

  • Injection quantity can be adjusted when fractured ground is encountered

  • Carbothix is resistant to dilute acids and alkalis as well as fats

  • Can be pumped long distances (up to 500 m) improving operational flexibility

  • 12 Month shelf life

Configurations

PUNCHED SHEAR STRENGTH

TIME

5 MPa

3 Minutes

14 MPa

5 MInutes

25 MPa

1 Hour

Tests performed @ 25°C. Properties listed are only indicative and may vary with temperature, mining conditions, strata conditions, equipment, bolt hole annulus, injection qty etc.

GEL TIME

CURE TIME

10 Sec

33 Sec

TIME

ULTIMATE COMPRESSIVE STRENGTH

1 Hour

70 MPa

24 Hours

75 MPa

Product Options

  • Carbothix 1:2 Slow Set

  • Carbothix Fast

Industry sectors

  • Coal Mining
  • Hard Rock Mining
  • Construction
  • Energy

Common use

  • Anchoring
  • Chemical injection
  • Grouting
  • Structural repair and reinforcement
  • Water control

Available Regions

  • North America
  • South America
